Synology DiskStation DS423 NAS | 4 Drive Bays | Realtek RTD1619B | 2x Gigabit Ethernet | Desktop | Black

Warranty	2 jaar via Complies
SKU	DS423
EAN	4711174724918
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Storage
Storage drives installed:	No
Number of storage drives supported:	4
Installed storage drive type:	No
Supported storage drive types:	HDD & SSD
Supported storage drive interfaces:	Serial ATA
Storage drive size:	2.5/3.5"
Storage drive sizes supported:	2.5,3.5"
Maximum supported storage capacity:	108 TB
RAID support:	Yes
RAID levels:	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays:	Yes
Supported file systems:	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Processor
Processor manufacturer:	Realtek
Processor family:	Realtek
Processor model:	RTD1619B
Processor frequency:	1.7 GHz
Processor cores:	4
Memory
Internal memory type:	DDR4
Internal memory:	2 GB
Maximum RAM supported:	2 GB
Network
Ethernet LAN:	Yes
Ethernet LAN data rates:	10,100,1000 Mbit/s
Copper ethernet cabling technology:	10BASE-T, 100BASE-T, 1000BASE-T
iSCSI support:	Yes
Supported network protocols:	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ports & interfaces
Ethernet LAN (RJ-45) ports:	2
USB port:	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:	2
Design
Cooling type:	Active
Product colour:	Black
Number of fans:	2 fan(s)
Fan diameter:	8 cm
Fan diameter 2:	8 cm
LED indicators:	Yes
Built-in display:	No
Cable lock slot:	Yes
Cable lock slot type:	Kensington
Built-in speaker(s):	No
Performance
Type:	NAS
Device class:	Home & Home Office
Backup function:	Yes
Backup features:	Cloud, iSCSI LUN
Buzzer:	Yes
Multilingual support:	Yes
Number of users:	1024 user(s)
Noise level:	22.9 dB
Card reader integrated:	No
Security algorithms:	HTTPS, SSH, SSH-1.5, SSH-2, SSL/TLS
Access Control List (ACL):	Yes
Reset button:	Yes
On/off switch:	Yes
Built-in FTP server:	Yes
Browser supported:	Google Chrome, Firefox, Microsoft Edge, Safari
System log:	Yes
Software
Operating system installed:	DiskStation Manager
Power
Power supply location:	External
Power supply unit (PSU) capacity:	90 W
Number of power supply units:	1
Redundant power supply (RPS) support:	No
Power consumption (typical):	32.41 W
Power consumption (sleep):	4.97 W
AC input voltage:	100 - 240 V
AC input frequency:	50 / 60 Hz
Weight & dimensions
Width:	184 mm
Depth:	168 mm
Height:	230 mm
Weight:	2.21 kg
Packaging content
External power adapter:	Yes
Cables included:	AC, LAN (RJ-45)
Power cables quantity:	1
Technical details
Sustainability certificates:	CCC, CE, Federal Communications Commission (FCC), UKCA
Operational conditions
Operating temperature (T-T):	0 - 40 Â°C
Operating relative humidity (H-H):	5 - 95%
Storage temperature (T-T):	-20 - 60 Â°C
Storage relative humidity (H-H):	5 - 95%
Operating altitude:	0 - 5000 m

Productomschrijving

The Synology DiskStation DS423 offers versatile storage options for both HDDs and SSDs, supporting SATA interfaces and disk sizes of 2.5 inches and 3.5 inches. Powered by a Realtek RTD1619B processor, this NAS provides powerful performance for various applications.

With 2GB of DDR4 internal memory and support for up to 2GB of RAM, the DS423 ensures smooth and efficient data processing. With Ethernet LAN connectivity and data transfer speeds of up to 10/100/1000 Mbps, you can seamlessly connect to your network and transfer data quickly.
