Ubiquiti UniFi Dream Machine Pro Max | Managed Gateway | 2.5G Ethernet | 1U Rackmount | Silver

Warranty	2 jaar via Fabrikant
SKU	UDM-PRO-MAX
EAN	0810084693254
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Management features
Switch type:	Managed
Quality of Service (QoS) support:	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:	9
Basic switching RJ-45 Ethernet ports type:	2.5G Ethernet (100/1000/2500)
Gigabit Ethernet (copper) ports quantity:	1
2.5G Ethernet (copper) ports quantity:	1
SFP+ module slots quantity:	2
Power connector:	DC-in jack
Network
10G support:	Yes
Policy-based routing:	Yes
Ethernet LAN data rates:	10,100,1000,2500 Mbit/s
VLAN support:	Yes
Virtual LAN features:	IP subnetâ€“based VLAN
Data transmission
Throughput:	5 Gbit/s
Security
DHCP features:	DHCP relay, DHCP server
IGMP proxy:	Yes
Design
Rack mounting:	Yes
Stackable:	No
Form factor:	1U
Product colour:	Grey
Housing material:	Aluminium, Galvanized steel
Reset button:	Yes
LED indicators:	Activity, Error, Link, Ready
Display type:	LCM
Performance
Built-in processor:	Yes
Processor model:	ARM Cortex-A57
Processor frequency:	2000 MHz
Memory type:	DDR4-SDRAM
Internal memory:	8000 MB
Flash memory:	32000 MB
Power
Power source:	AC/DC
Power supply included:	Yes
Redundant power supply (RPS) support:	Yes
Number of power supply units:	1
AC input voltage:	100 - 240 V
AC input frequency:	50/60 Hz
DC input voltage:	12 V
Input current:	2 A
Power consumption (max):	60 W
Power over Ethernet (PoE)
Power over Ethernet (PoE):	No
Technical details
Compliance certificates:	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Operational conditions
Operating temperature (T-T):	-10 - 40 Â°C
Operating relative humidity (H-H):	5 - 95%
Weight & dimensions
Width:	442.4 mm
Depth:	285.6 mm
Height:	43.7 mm
Weight:	4.7 kg
Sustainability
Sustainability compliance:	Yes
Packaging data
Cables included:	AC
User guide:	Yes
Rack mount kit:	Yes

Productomschrijving

Professional-grade, rack-mount Cloud Gateway with 10 Gbps performance, multi-WAN load balancing, and two NVR drive bays designed for large-scale, multi-application UniFi sites.
