be quiet! TFX POWER 3 | 300W Bronze TFX PSU | Power Supply

Warranty	5 jaar via be Quiet
SKU	BN322
EAN	4260052188286
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Power
Total power:	300 W
Peak power:	350 W
AC input voltage:	100 - 240 V
AC input frequency:	50/60 Hz
Input current:	4/1.5 A
Maximum input current (@110V):	4 A
Maximum input current (@220V):	1.5 A
Power factor:	0.96
Power Factor Correction (PFC) type:	Active
Combined power (+3.3V):	85 W
Combined power (+12V):	300 W
Combined power (+5V):	85 W
Max output current (+3.3V):	16 A
Max output current (+12V1):	25 A
Max output current (+5V):	16 A
Max output current (-12V):	0.3 A
Max output current (+5Vsb):	2.5 A
Hold time:	22 ms
Efficiency:	86.4%
Power protection features:	Over current, Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector:	20+4 pin ATX
Motherboard power cable length:	35 cm
Number of SATA power connectors:	3
SATA power cable length:	300,450,600 mm
Peripheral (Molex) power connectors (4-pin):	2
Peripheral (Molex) power cable length:	300,450 mm
PCI Express power connectors (6+2 pin):	1
PCI Express power cable length:	40 cm
CPU P4 connector (4-pin):	1
CPU power cable length:	35 cm
Floppy drive power connector:	1
Floppy disk drive cable length:	60 cm
Cabling type:	Non-Modular
Performance
Purpose:	PC
Power supply unit (PSU) form factor:	TFX
80 PLUS certification:	80 PLUS Bronze
ATX version:	2.52
EPS version:	2.92
Noise level:	29.1 dB
Bearing technology:	Rifle
Mean time between failures (MTBF):	100000 h
Safety:	CE, CB, TÃœV, CU
Design
Product colour:	Black
Cooling type:	Active
Fan diameter:	8 cm
Number of fans:	1 fan(s)
Technical details
Sustainability compliance:	Y
Sustainability certificates:	ENERGY STAR, ErP, RoHS, WEEE
Weight & dimensions
Width:	85 mm
Depth:	175 mm
Height:	65 mm
Weight:	900 g
Packaging data
Package width:	159 mm
Package depth:	80 mm
Package height:	215 mm
Package weight:	1.24 kg
Package type:	Box
Logistics data
Shipping (inner) case length:	47.4 cm
Shipping (inner) case width:	27.5 cm
Shipping (inner) case height:	19.5 cm
Quantity per shipping (inner) case:	6 pc(s)
Shipping (inner) case weight:	8.25 kg
Other features
Harmonized System (HS) code:	84733020

Productomschrijving

Meet the be quiet! TFX POWER 3 300W Bronze, the perfect power supply for your PC. With a total power of 300 watts and a peak power of 350 watts, this power supply delivers reliable performance for your system.

Featuring a 20+4 pin ATX motherboard connector and cables of 35 cm for the motherboard and 300, 450, and 600 mm for SATA power, this power supply is ideal for your PC setup.

The be quiet! TFX POWER 3 is designed with efficiency in mind, with an 80 PLUS Bronze certification for energy savings.

The black color and active cooling with an 8 cm fan ensure that this power supply is not only powerful but also quiet and attractive.

With dimensions of 85 mm wide, 175 mm deep, and 65 mm high, this power supply fits easily into your TFX power supply case.
