TP-Link TL-SG1218MPE | Managed Smart Switch | 18 Ports | Gigabit Ethernet (10/100/1000 Mbps) | 16x PoE+ (192 W) | 2x SFP | VLAN/QoS | Black

Warranty	3 jaar via Complies
SKU	TL-SG1218MPE
EAN	6935364086923
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Management features
Switch type:	Managed
Web-based management:	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:	16
Basic switching RJ-45 Ethernet ports type:	Gigabit Ethernet (10/100/1000)
SFP module slots quantity:	2
Network
Networking standards:	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support:	N
Copper ethernet cabling technology:	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported:	Cat3, Cat4, Cat5, Cat5e, Cat6
Port mirroring:	Y
Link aggregation:	Y
Broadcast storm control:	Y
Auto MDI/MDI-X:	Y
Auto-negotiation:	Y
VLAN support:	Y
Number of VLANs:	32
Data transmission
MAC address table:	8000 entries
Switching capacity:	36 Gbit/s
Forwarding rate:	23.8 Mpps
Store-and-forward:	Y
Number of queues:	4
Jumbo frames support:	Y
Jumbo frames:	9000
Packet buffer memory:	4.1 MB
Optical fiber
Fiber ethernet cabling technology:	1000BASE-X
Security
IGMP snooping:	Y
Design
Rack mounting:	Y
Product colour:	Black
Number of fans:	2 fan(s)
Certification:	CE, FCC, RoHS
Power
Power supply included:	Y
AC input voltage:	100 - 240 V
AC input frequency:	50/60 Hz
Power consumption (max):	217.22 W
Power over Ethernet (PoE)
Power over Ethernet (PoE):	Y
Power over Ethernet plus (PoE+) ports quantity:	16
Total Power over Ethernet (PoE) budget:	192 W
Operational conditions
Operating temperature (T-T):	0 - 50 Â°C
Storage temperature (T-T):	-40 - 70 Â°C
Operating relative humidity (H-H):	10 - 90%
Storage relative humidity (H-H):	5 - 90%
Heat dissipation:	741.15 BTU/h
Weight & dimensions
Width:	440 mm
Depth:	180 mm
Height:	44 mm
Packaging data
Cables included:	AC
User guide:	Y
Rack mount kit:	Y
Package width:	528 mm
Package depth:	250 mm
Package height:	80 mm
Package weight:	2.91 kg
Logistics data
Harmonized System (HS) code:	85176990

Productomschrijving

TL-SG1218MPE complies with the 802.3af/at PoE+ standard and supports up to 30W of power on each PoE port. The total high PoE power budget is up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.

When the total power consumption exceeds 192W, the intelligent power management will switch off the power supply of the lower priority port to ensure the power supply of the high priority port and protect the device from overload.

TL-SG1218MPE provides network monitoring for users to observe traffic behaviour. Through its web-based user interface and management tool, TL-SG1218MPE provides a variety of useful features, including network monitoring, traffic prioritisation and enhanced QoS.
