ASRock Z790 LiveMixer | Socket LGA 1700 | Intel Z790 | 4xDDR5 | ATX | Motherboard

Warranty	2 jaar via Complies
SKU	90-MXBK10-A0UAYZ
EAN	4710483940897
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Memory
Supported memory types:	DDR5-SDRAM
Number of memory slots:	4
Memory slots type:	DIMM
Memory channels:	Dual-channel
Maximum internal memory:	128 GB
Processor
Processor manufacturer:	Intel
Processor socket:	LGA 1700
Compatible processor series:	IntelÂ® Coreâ„¢ i5, IntelÂ® Coreâ„¢ i7, IntelÂ® Coreâ„¢ i9
Maximum number of SMP processors:	1
Internal I/O
USB 2.0 connectors:	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors:	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors:	1
Number of SATA III connectors:	4
Front panel audio connector:	Yes
ATX Power connector (24-pin):	Yes
CPU fan connector:	Yes
EPS power connector (8-pin):	Yes
TPM connector:	Yes
Thunderbolt headers:	1
RGB LED pin header:	Yes
Rear panel I/O ports
USB 2.0 ports quantity:	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:	2
Ethernet LAN (RJ-45) ports:	1
HDMI ports quantity:	1
DisplayPorts quantity:	1
DisplayPort version:	1.4
Headphone outputs:	1
Microphone in:	Yes
S/PDIF out port:	Yes
Network
Ethernet LAN:	Yes
Ethernet interface type:	2.5 Gigabit Ethernet
LAN controller:	Dragon RTL8125BG
Wi-Fi:	No
Expansion slots
PCI Express x1 (Gen 3.x) slots:	1
PCI Express x16 (Gen 4.x) slots:	2
PCI Express x16 (Gen 5.x) slots:	1
Number of M.2 (M) slots:	1
BIOS
BIOS type:	UEFI AMI
BIOS memory size:	128 Mbit
Storage controllers
Supported storage drive interfaces:	M.2, SATA III
RAID support:	Yes
RAID levels:	0, 1, 5, 10
Features
Component for:	PC
Motherboard form factor:	ATX
Motherboard chipset family:	Intel
Motherboard chipset:	Intel Z790
Audio chip:	Realtek ALC897
Audio output channels:	7.1 channels
Windows operating systems supported:	Windows 10 x64, Windows 11 x64
Weight & dimensions
Width:	305 mm
Depth:	244 mm

Productomschrijving

De Asrock Z790 LiveMixer is een krachtig ATX-moederbord ontworpen voor Intel-processors. Met de LGA 1700-socket ondersteunt het Intel® Core™ i5, i7 en i9 processors en biedt het tot 128 GB DDR5-SDRAM geheugen via DIMM-slots.

Voor opslag beschikt het over M.2- en SATA III-interfaces en ondersteunt het RAID-configuraties (0, 1, 5, 10) voor verbeterde prestaties en gegevensbeveiliging. De 2.5 Gigabit Ethernet-poort, aangedreven door de Dragon RTL8125BG LAN-controller, garandeert snelle en betrouwbare netwerkverbindingen. Dit moederbord biedt de prestaties en veelzijdigheid die je nodig hebt voor een krachtige pc.
