be quiet! Pure Power 12 | 850 Watt Gold ATX 3.1 PSU | Power Supply | PSU

Warranty	2 jaar via Fabrikant
SKU	BP004EU
EAN	4260052191194
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Power
Total power:	850 W
Peak power:	900 W
AC input voltage:	100 - 240 V
AC input frequency:	50/60 Hz
Maximum input current (@110V):	12 A
Maximum input current (@220V):	6 A
Power factor:	0.98
Power Factor Correction (PFC) type:	Active
Number of +12V rail(s):	1
Combined power (+3.3V):	120 W
Combined power (+12V):	850 W
Combined power (+5V):	120 W
Combined power (-12V):	3.6 W
Combined power (+5Vsb):	15 W
Max output current (+3.3V):	22 A
Max output current (+12V1):	70.9 A
Max output current (+5V):	22 A
Max output current (-12V):	0.3 A
Max output current (+5Vsb):	3 A
Hold time:	17.34 ms
Efficiency:	90.5%
Power protection features:	Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Under voltage
Ports & interfaces
Motherboard power connector:	20+4 pin ATX
Motherboard power cable length:	55 cm
Number of SATA power connectors:	6
SATA power cable length:	500,650,800,950 mm
Peripheral (Molex) power connectors (4-pin):	1
Peripheral (Molex) power cable length:	800 mm
PCI Express power connectors (6+2 pin):	3
PCI Express power connectors (12-pin):	1
PCI Express power cable length:	60 cm
CPU power connector (4+4 pin):	Yes
CPU power cable length:	60 cm
Cabling type:	Non-Modular
Performance
Purpose:	PC
Power supply unit (PSU) form factor:	ATX
80 PLUS certification:	80 PLUS Gold
ATX version:	3.1
EPS version:	2.92
Noise level:	25.1 dB
Bearing technology:	Rifle
Mean time between failures (MTBF):	100000 h
Design
Product colour:	Black
Cooling type:	Active
Fan diameter:	12 cm
Number of fans:	1 fan(s)
On/off switch:	Yes
Packaging content
Cables included:	AC
Cable tie(s) included:	Yes
Certificates
Compliance certificates:	CB, CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE, cTUVus
Technical details
Sustainability certificates:	ENERGY STAR, ErP, Triman
Operational conditions
Operating temperature (T-T):	0 - 40 Â°C
Storage temperature (T-T):	-20 - 70 Â°C
Operating relative humidity (H-H):	0 - 90%
Storage relative humidity (H-H):	0 - 95%
Weight & dimensions
Width:	86 mm
Depth:	160 mm
Height:	150 mm
Weight:	2.7 kg
Packaging data
Package width:	133 mm
Package depth:	320 mm
Package height:	210 mm
Package weight:	3.1 kg
Logistics data
Shipping (inner) case length:	56 cm
Shipping (inner) case width:	24 cm
Shipping (inner) case height:	34 cm
Shipping (inner) case net weight:	13.4 kg
Quantity per shipping (inner) case:	4 pc(s)
Warranty period:	10 year(s)
Other features
Screws included:	Yes

Productomschrijving

Exceptional quiet, superior features
Pure Power 12 850W is ATX 3.1 compliant and PCIe 5.1 compatible and offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers remarkable convenience and outstanding compatibility.
