Intel Core i7-14700K | 20 Core | 3.4GHz (5.6GHz Turbo) | LGA 1700 | Processor | CPU

Warranty	2 jaar via Complies
SKU	BX8071514700K
EAN	5032037278485
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Processor
Processor manufacturer:	Intel
Processor family:	IntelÂ® Coreâ„¢ i7
Processor generation:	Intel Core i7-14xxx
Processor model:	i7-14700K
Processor cores:	20
Processor socket:	LGA 1700
Box:	Yes
Processor threads:	28
Processor operating modes:	64-bit
Performance cores:	8
Efficient cores:	12
Processor boost frequency:	5.6 GHz
Performance-core boost frequency:	5.5 GHz
Performance-core base frequency:	3.4 GHz
Efficient-core boost frequency:	4.3 GHz
Efficient-core base frequency:	2.5 GHz
Processor cache:	33 MB
Processor cache type:	Smart Cache
Processor base power:	125 W
Maximum turbo power:	253 W
Stepping:	B0
Maximum number of DMI lanes:	8
Memory bandwidth supported by processor (max):	89.6 GB/s
Processor codename:	Raptor Lake
Processor ARK ID:	236783
Memory
Maximum internal memory supported by processor:	192 GB
Memory types supported by processor:	DDR4-SDRAM, DDR5-SDRAM
Memory channels:	Dual-channel
ECC:	Yes
Memory bandwidth (max):	89.6 GB/s
Graphics
On-board graphics adapter:	Yes
Discrete graphics adapter:	No
On-board graphics adapter model:	Intel UHD Graphics 770
On-board graphics adapter outputs supported:	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics adapter base frequency:	300 MHz
On-board graphics adapter dynamic frequency (max):	1600 MHz
Number of displays supported (on-board graphics):	4
On-board graphics adapter DirectX version:	12.0
On-board graphics adapter OpenGL version:	4.5
On-board graphics adapter maximum resolution (DisplayPort):	7680 x 4320 pixels
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel):	5120 x 3200 pixels
On-board graphics adapter maximum resolution (HDMI):	4096 x 2160 pixels
On-board graphics adapter refresh rate at maximum resolution (DisplayPort):	60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel):	120 Hz
On-board graphics adapter refresh rate at maximum resolution (HDMI):	60 Hz
On-board graphics adapter ID:	0xA780
Discrete graphics adapter model:	Not available
Number of execution units:	32
Multi-Format Codec Engines:	2
Features
Execute Disable Bit:	Yes
Idle States:	Yes
Thermal Monitoring Technologies:	Yes
Market segment:	Desktop
Use conditions:	Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes:	20
PCI Express slots version:	4.0, 5.0
PCI Express configurations:	1x16+1x4, 2x8+1x4
Supported instruction sets:	AVX 2.0, SSE4.1, SSE4.2
Scalability:	1S
CPU configuration (max):	1
Embedded options available:	No
Thermal solution specification:	PCG 2020A
Direct Media Interface (DMI) Revision:	4.0
Export Control Classification Number (ECCN):	5A992C
Commodity Classification Automated Tracking System (CCATS):	740.17B1
Processor special features
IntelÂ® Hyper Threading Technology (IntelÂ® HT Technology):	Yes
IntelÂ® Turbo Boost Technology:	2.0
IntelÂ® Quick Sync Video Technology:	Yes
IntelÂ® Clear Video HD Technology (IntelÂ® CVT HD):	Yes
IntelÂ® AES New Instructions (IntelÂ® AES-NI):	Yes
Enhanced Intel SpeedStep Technology:	Yes
IntelÂ® Speed Shift Technology:	Yes
IntelÂ® Turbo Boost Max Technology 3.0 frequency:	5.6 GHz
IntelÂ® Gaussian & Neural Accelerator (IntelÂ® GNA) 3.0:	Yes
IntelÂ® Control-flow Enforcement Technology (CET):	Yes
IntelÂ® Thread Director:	Yes
Intel VT-x with Extended Page Tables (EPT):	Yes
IntelÂ® Secure Key:	Yes
IntelÂ® OS Guard:	Yes
Intel 64:	Yes
Intel Virtualization Technology (VT-x):	Yes
Intel Virtualization Technology for Directed I/O (VT-d):	Yes
Intel Turbo Boost Max Technology 3.0:	Yes
IntelÂ® Boot Guard:	Yes
IntelÂ® Deep Learning Boost (IntelÂ® DL Boost):	Yes
IntelÂ® Volume Management Device (VMD):	Yes
Mode-based Execute Control (MBE):	Yes
IntelÂ® Standard Manageability (ISM):	Yes
Operational conditions
Tjunction:	100 Â°C
Technical details
OpenCL version:	3.0
Logistics data
Harmonized System (HS) code:	8542310001
Technical details
Launch date:	Q4'23
Status:	Launched
Weight & dimensions
Processor package size:	45 x 37.5 mm
Other features
L2 cache:	28672 KB
Maximum internal memory:	192 GB
Graphics output:	eDP 1.4b, DP 1.4a, HDMI 2.1

Productomschrijving

Discover the boundless performance of the Intel Core i7-14700K, a member of the Intel Core i7 processor family. This processor is designed to meet even the most demanding tasks, offering unparalleled computing power for desktops, workstations, and high-performance PCs.

Featuring an LGA 1700 processor socket and manufactured by Intel, you can count on the latest technology and compatibility with future upgrades. The Intel Core i7-14700K supports dual-channel memory, resulting in fast data transfers and seamless multitasking. With support for up to 192 GB of internal memory via DDR4-SDRAM and DDR5-SDRAM memory types, you have more than enough space for demanding applications and tasks.

Whether you are assembling a desktop, a workstation, or a PC/tablet, the Intel Core i7-14700K is ready for any challenge. With support for PCI Express slots of version 4.0 and 5.0, you are future-proof and can take advantage of the fastest data transmission.
