Intel Core i5-13500 | 14 Cores | 2.5GHz (4.8GHz Turbo) | LGA 1700 | Processor | CPU

Warranty	3 jaar via Complies
SKU	BX8071513500
EAN	5032037260251
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Processor
Processor manufacturer:	Intel
Processor family:	IntelÂ® Coreâ„¢ i5
Processor generation:	13th gen IntelÂ® Coreâ„¢ i5
Processor model:	i5-13500
Processor cores:	14
Processor socket:	LGA 1700
Box:	Y
Processor threads:	20
Processor operating modes:	64-bit
Performance cores:	6
Efficient cores:	8
Processor boost frequency:	4.8 GHz
Performance-core boost frequency:	4.8 GHz
Performance-core base frequency:	2.5 GHz
Efficient-core boost frequency:	3.5 GHz
Efficient-core base frequency:	1.8 GHz
Processor cache:	24 MB
Processor cache type:	Smart Cache
Processor base power:	65 W
Maximum turbo power:	154 W
Bus type:	DMI4
Maximum number of DMI lanes:	8
Memory bandwidth supported by processor (max):	76.8 GB/s
Processor codename:	Raptor Lake
Processor ARK ID:	230580
Memory
Maximum internal memory supported by processor:	128 GB
Memory types supported by processor:	DDR4-SDRAM, DDR5-SDRAM
Memory channels:	Dual-channel
ECC:	Y
Memory bandwidth (max):	76.8 GB/s
Graphics
On-board graphics adapter:	Y
Discrete graphics adapter:	N
On-board graphics adapter model:	Intel UHD Graphics 770
On-board graphics adapter outputs supported:	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics adapter base frequency:	300 MHz
On-board graphics adapter dynamic frequency (max):	1550 MHz
Number of displays supported (on-board graphics):	4
On-board graphics adapter DirectX version:	12.0
On-board graphics adapter OpenGL version:	4.5
On-board graphics adapter maximum resolution (DisplayPort):	7680 x 4320 pixels
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel):	5120 x 3200 pixels
On-board graphics adapter maximum resolution (HDMI):	4096 x 2160 pixels
On-board graphics adapter refresh rate at maximum resolution (DisplayPort):	60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel):	120 Hz
On-board graphics adapter refresh rate at maximum resolution (HDMI):	60 Hz
On-board graphics adapter ID:	0x4680
Discrete graphics adapter model:	Not available
Number of execution units:	32
Multi-Format Codec Engines:	2
Features
Execute Disable Bit:	Y
Idle States:	Y
Thermal Monitoring Technologies:	Y
Market segment:	Desktop
Use conditions:	PC/Client/Tablet, Workstation
Maximum number of PCI Express lanes:	20
PCI Express slots version:	5.0, 4.0
PCI Express configurations:	1x16+1x4, 2x8+1x4
Supported instruction sets:	SSE4.1, SSE4.2, AVX 2.0
Scalability:	1S
CPU configuration (max):	1
Embedded options available:	Y
Direct Media Interface (DMI) Revision:	4.0
Export Control Classification Number (ECCN):	5A992C
Commodity Classification Automated Tracking System (CCATS):	740.17B1
Processor special features
IntelÂ® Hyper Threading Technology (IntelÂ® HT Technology):	Y
IntelÂ® Turbo Boost Technology:	2.0
IntelÂ® Quick Sync Video Technology:	Y
IntelÂ® Clear Video HD Technology (IntelÂ® CVT HD):	Y
IntelÂ® AES New Instructions (IntelÂ® AES-NI):	Y
Enhanced Intel SpeedStep Technology:	Y
Intel Trusted Execution Technology:	Y
IntelÂ® Speed Shift Technology:	Y
IntelÂ® Gaussian & Neural Accelerator (IntelÂ® GNA) 3.0:	Y
IntelÂ® Control-flow Enforcement Technology (CET):	Y
IntelÂ® Thread Director:	Y
Intel VT-x with Extended Page Tables (EPT):	Y
IntelÂ® Secure Key:	Y
IntelÂ® OS Guard:	Y
Intel 64:	Y
Intel Virtualization Technology (VT-x):	Y
Intel Virtualization Technology for Directed I/O (VT-d):	Y
Intel Turbo Boost Max Technology 3.0:	N
IntelÂ® Boot Guard:	Y
IntelÂ® Deep Learning Boost (IntelÂ® DL Boost):	Y
IntelÂ® Volume Management Device (VMD):	Y
Mode-based Execute Control (MBE):	Y
IntelÂ® Standard Manageability (ISM):	Y
IntelÂ® Virtualization Technology with Redirect Protection (VT-rp):	Y
Operational conditions
Tjunction:	100 Â°C
Technical details
OpenCL version:	3.0
Packaging data
Package type:	Retail box
Logistics data
Harmonized System (HS) code:	8542310001
Technical details
Target market:	Gaming
Launch date:	Q1'23
Status:	Launched
Weight & dimensions
Processor package size:	45 x 37.5 mm
Other features
L2 cache:	11776 KB
Maximum internal memory:	128 GB
Graphics output:	eDP 1.4b, DP 1.4a, HDMI 2.1

Productomschrijving

The BX8071513500 Intel Core i5-13500 CPU is a powerful processor suitable for intensive computing tasks. With 24 MB Smart Cache, this processor offers significantly faster performance compared to the previous generation.

The processor is easy to install and comes in a handy box with the necessary documentation. The processor supports DDR4 memory and offers excellent energy efficiency for a more sustainable and environmentally conscious computing experience. The processor is also capable of 4K video playback and supports Intel Wi-Fi 6 technology for faster wireless connectivity.
