Zyxel XGS1930-28HP | Managed L3 Switch | 28 Ports | Gigabit Ethernet (10/100/1000 Mbps) | PoE | Black

Warranty	2 jaar via Complies
SKU	XGS1930-28HP-EU0101F
EAN	4718937595006
Condition	New

Ontdek onze prijzen

Specifications
Product Description
Alternatives
Print Spec Sheet

Management features
Switch type:	Managed
Switch layer:	L3
Quality of Service (QoS) support:	Y
Web-based management:	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:	24
Basic switching RJ-45 Ethernet ports type:	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity:	4
Fiber optic connector:	SFP+
Network
Networking standards:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support:	Y
Copper ethernet cabling technology:	10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring:	Y
IP routing:	Y
Routing entries:	32
Flow control support:	Y
Link aggregation:	Y
Broadcast storm control:	Y
Spanning tree protocol:	Y
VLAN support:	Y
Virtual LAN features:	Voice VLAN, Port-based VLAN
Number of VLANs:	4000
Multicast features
Multicast support:	Y
Data transmission
MAC address table:	16000 entries
Switching capacity:	128 Gbit/s
Forwarding rate:	95.2 Mpps
Static route:	Y
Path MTU discovery:	Y
Packet buffer memory:	1.5 MB
Security
DHCP features:	DHCP relay, DHCPv6 relay, DHCP client
Access Control List (ACL):	Y
IGMP snooping:	Y
Security algorithms:	802.1x RADIUS, HTTPS, SHA-2, SNMPv3, SSL/TLS
SSH/SSL support:	Y
Loop protection:	Y
Authentication:	Guest VLAN, MAC-based authentication, Port-based authentication
Password protection:	Y
CPU defense:	Y
Protocols
GARP VLAN Registration Protocol (GVRP):	Y
Design
Rack mounting:	Y
Product colour:	Black
Safety:	LVD, BSMI
Electromagnetic compatibility:	FCC 15 A, CE A, BSMI EMC
Certification:	RoHS
Performance
Internal memory:	512 MB
Flash memory:	32 MB
Noise level:	28.5 dB
Mean time between failures (MTBF):	1369432 h
Power
AC input voltage:	100 - 240 V
AC input frequency:	50 - 60 Hz
Power consumption (max):	471 W
Power over Ethernet (PoE)
Power over Ethernet (PoE):	Y
Power over Ethernet (PoE) ports quantity:	24
Total Power over Ethernet (PoE) budget:	375 W
Operational conditions
Operating temperature (T-T):	0 - 50 Â°C
Storage temperature (T-T):	-40 - 70 Â°C
Operating relative humidity (H-H):	10 - 95%
Storage relative humidity (H-H):	10 - 95%
Heat dissipation:	1606.11 BTU/h
Weight & dimensions
Width:	441 mm
Depth:	330 mm
Height:	44 mm
Weight:	4.6 kg
Packaging data
Cables included:	AC
Rack mount kit:	Y
Package width:	585 mm
Package depth:	503 mm
Package height:	95 mm
Package weight:	5.82 kg
Logistics data
Harmonized System (HS) code:	85176990

Productomschrijving

Are you looking for an advanced networking solution for your business? Allow us to introduce you to the Zyxel XGS1930-28HP. This managed switch with Layer 3 support offers impressive performance and features to optimize your network.

With 24 Gigabit Ethernet (10/100/1000) RJ-45 ports, this switch provides ample connectivity for all your devices. Whether you need to connect desktops, servers, printers, or other network devices, this switch can handle it.

The Zyxel XGS1930-28HP boasts a powerful MAC address table with a capacity for 16000 entries, meaning it can effortlessly manage large volumes of network traffic without performance loss.

More…
